HARDWARE FEATURES | |
Interface | 1 × Gigabit WAN Port, 4 × Gigabit LAN Ports 1 × Tpye A USB 3.0 Port |
Button | WPS/Wi-Fi Button, LED On/Off Button, Power On/Off Button, Reset Button |
External Power Supply | 12 V/2 A |
Dimensions ( W x D x H ) | 10.2 × 5.3 × 1.5 in (260.2 x 135.0 x 38.6 mm) |
Antenna | 4 × External Antennas |
WIRELESS FEATURES | |
Wireless Standards | IEEE 802.11ax/ac/n/a 5 GHz IEEE 802.11ax/n/b/g 2.4 GHz |
Frequency | 2.4 GHz and 5 GHz |
Signal Rate | 5 GHz: 2402 Mbps(802.11ax), 2.4 GHz: 574 Mbps(802.11ax) compatible with 802.11a/b/g/n/ac Wi-Fi standards |
Reception Sensitivity | 5 GHz: 11a 6Mbps:-97dBm, 11a 54Mbps:-79dBm 11ac VHT20_MCS0:-96dBm, 11ac VHT20_MCS11:-66dBm 11ac VHT40_MCS0:-94dBm, 11ac VHT40_MCS11:-63dBm 11ac VHT80_MCS0:-91dBm, 11ac VHT80_MCS11:-60dBm 11ac VHT160_MCS0:-88dBm, 11ac VHT160_MCS11:-55dBm 11ax HE20_MCS0:-95dBm, 11ax HE20_MCS11:-63dBm 11ax HE40_MCS0:-92dBm, 11ax HE40_MCS11:-60dBm 11ax HE80_MCS0:-89dBm, 11ax HE80_MCS11:-58dBm 11ax HE160_MCS0:-85dBm, 11ax HE160_MCS11:-55dBm 2.4 GHz: 11g 6Mbps:-97dBm, 11a 54Mbps:-79dBm 11n HT20_MCS0:-97dBm, 11n HT20_MCS7:-78dBm 11n HT40_MCS0:-95dBm, 11n HT40_MCS7:-75dBm 11ac VHT20_MCS0:-96dBm, 11ac VHT20_MCS11:-67dBm 11ac VHT40_MCS0:-94dBm, 11ac VHT40_MCS11:-64dBm 11ax HE20_MCS0:-96dBm, 11ax HE20_MCS11:-64dBm 11ax HE40_MCS0:-93dBm, 11ax HE40_MCS11:-61dBm |
Wireless Functions | Enable/Disable Wireless Radio, WMM, Wireless Statistics |
Wireless Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions |
Transmission Power | CE: <20dBm(2.4 GHz), <23dBm(5.15 GHz~5.35 GHz); <30dBm(5.47 GHz~5.725 GHz) FCC:<30dBm(2.4 GHz & 5.15 GHz~5.825 GHz) |
Guest Network | 1 × 2.4 GHz Guest Network 1 × 5 GHz Guest Network |
SOFTWARE FEATURES | |
Quality of Service | Device and Application Prioritisation |
WAN Type | Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access) |
Management | Access Control, Local Management, Remote Management |
DHCP | Server, DHCP Client List, Address Reservation |
Port Forwarding | Virtual Server, Port Triggering, UPnP, DMZ |
Dynamic DNS | DynDns, NO-IP, TP-Link |
Access Control | Parental Controls, Local Management Control, Host List, White List, Black List |
Firewall Security | DoS, SPI Firewall, IP and MAC Address Binding |
Protocols | IPv4, IPv6 |
USB Sharing | Supports Samba(Storage)/FTP Server/Media Server |
OTHERS | |
Package Contents | Wireless Router Archer AX50 Power Adapter RJ45 Ethernet Cable Quick Installation Guide |
System Requirements | Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser Cable or DSL Modem Subscription with an internet service provider (for internet access) |
Environment | Operating Temperature: 0℃~40℃ (32℉ ~104℉) Storage Temperature: -40℃~70℃ (-40℉ ~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
Certifications | CE, FCC, RoHS |
